Coyle Strapping & Supply is an authorized distributor of Signode, Acme and Polychem plastic strapping systems and seals. We offer a full line of manual, pneumatic and battery operated plastic strapping tools as well as semi-automatic and fully automatic plastic strapping systems. Available is a full line of hand grade and machine grade polypropylene and polyester strapping. We are also an authorized Universal,  and Carolina strapping distributor.

Polypropylene strapping is a good choice for light to medium duty applications, including palletizing, unitizing, bundling, carton closure and reinforcement.

Hand Grade Polypropylene

For use with hand tool applications, pneumatic and battery combination tools. The stronger alternative to twine, stretch wrap or tape

Width & Thickness Feet Strength Core Color
1/2″ x .015″ 9000 250# 16 x 6 B
1/2″ x .017″ 9000 300# 16 x 6 B
1/2″ x .021″ 9000 400# 16 x 6 B
1/2″ x .026″ 6600 500# 16 x 6 B
1/2 x .026 7200 500# 16 x 6 B
1/2″ x .031″ 6600 600# 16 x 6 B, Y
1/2″ x .031″ 7200 600# 16 x 6 B
5/8″ x .030″ 3500 1000# 16 x 6 B

* Other Sizes Available

 Polyester Strapping

  Signode Catalog

Machine Grade Polypropylene

  • For light, medium and some heavy duty use.
  • For a variety of applications – bundling, palletizing and unitizing.
  • Guaranteed to work in all manufacturers’ equipment.
  • Economical – reliable – smooth running.
  • Absorbs shock better than other materials.
  • For boxing food products, produce, fish, chicken, meat, etc.
  • The standard for bundling corrugated boxes, newspapers, magazines and cut paper.
Color Core Size Nominal Width Nominal Thickness Nominal Break Footage
W 8 x 8 5mm .017″ 110# 24,000
W 8 x 8 5mm .018″ 130# 23,000
W/Y 8 x 8 1/4″ .024″ 200# 18,000
W/Y 9 x 8 1/4″ .024″ 200# 18,000
B/C/W/Y 8 x 8 3/8″ .024″ 300# 12,900
B/C/W/Y 9 x 8 3/8″ .024″ 300# 12,900
B/C/W/Y 8 x 8 1/2″ .023″ 350# 9,900
B/C/W/Y 9 x 8 1/2″ .023″ 350# 9,900
W 8 x 8 1/2″ .027″ 500# 8,200

* Other Sizes Available

FOR USE IN SIGNODE FULLY AUTOMATIC STRAPPING MACHINES

Strap Name Standard Color Part
Number		 Strap
Width		 Average
Strength		 Approx.
Length per Coil		 Approx. Coil
Outside Dia.		 Core
Size Inside Dia.		 Approx.
Coil Width		 Coil Weight Standard Package
Coils/Pallet		 Strapping
Application Methods
inch lbs N feet inch inch inch lbs.
Light
Duty
Contrax		 LD 213 Clear 2X1602 1/4 145 640 21,000 16 4 6 26 30 ML Power
Strapping Machines
LD 213 Yellow 2X1603
LD 216 Clear 2X1604 1/4 200 890 16,500 16 4 6 25
LD 216 Yellow 2X1605
Heavy
Duty
Contrax		 HD 719 Clear 2X1610 7/16 400 1780 12,000 24 16 6 36 12 MOD-710 Power Strapping Machines,
Pneumatic Tension-Weld Tools
HD 719 Black 2X1611
HD 723 Clear 2X1612 7/16 500 2220 9,000 24 16 6 34
HD 723 Black 2X1613
HD 729 Black 2X1618 7/16 600 2670 7,700 24 16 6 36
816 Black 010366 1/2 500 2220 8,000 24 16 6 33 Pneumatic Tension-Weld Tools,
Hand Tools using metal seals
816 Black 010385 1/2 600 2670 7,000 24 16 6 35
LB, SP
Light Duty
Contrax		 LB 112 Clear 2X1844 3/16 100 445 30,000 16 7.88 7.8 28 24 LBX Power Strapping Machines
LB 112 Yellow 2X1870
LB 212 Clear 2X1845 1/4 150 667 24,000 16 7.88 7.8 27
LB 212 Yellow 2X1848
LB 113 Clear 2X1601 3/16 120 530 25,000 16 7.88 7.8 31 24 LB, SP & SureTyer
Power Strapping Machines
LB 113 Yellow 2X1709
SP 216 Clear 2X1606 1/4 200 890 18,000 16 7.88 7.8 28
SP 216 Yellow 2X1607
HB, SP
General
Duty
Contrax		 HB 612 Clear 2X1738 3/8 225 1000 16,000 16 7.88 7.8 29 24 HBX Power Strapping Machines
HB 612 Black 2X1727
HB 812 Clear 2X1885 1/2 300 1330 12,000 16 7.88 7.8 27
HB 812 Black 2X1886
SP 616 Clear 2X1608 3/8 300 1330 12,000 16 7.88 7.8 28 24 HB, SP & SureTyer
Power Strapping Machines
SP 616 Black 2X1609
SP 719 Clear 2X1614 7/16 400 1780 9,000 16 7.88 7.8 28
SP 719 Black 2X1615
SP 723 Clear 2X1616 7/16 500 2220 7,500 16 7.88 7.8 27
SP 723 Black 2X1617

Polyester strapping can be tensioned to a higher percentage of its break strength than any other strapping material. It provides superior retained tension under hot, humid conditions and is more resistant to such environments than other plastic strapping. It also provides a greater load stability during storage and shipping.

Hand Grade Polyester

  • For all applications – light, medium, heavy duty
  • Broadest selection – sizes, colors, and footages.
  • Largest stocked inventory.
  • Competitive prices.
  • Highest quality
Width & Thickness Feet Strength Core Color
1/2″ x .020″ 7200 600# 16 x 6 B
1/2″ x .028″ 6500 820# 16 x 6 G
5/8″ x .020″ 5700 750# 16 x 6 B
5/8″ x .030″ 3600 1100# 16 x 6 B
5/8″ x .035″ 4000 1400# 16 x 6 B/G
5/8″ x .040″ 4000 1400# 16 x 6 B/G

* Other Sizes Available

Signode Polyester Strapping

Strap Name Standard Color Part Number Strap Width Average Strength Approx. Length per Coil Approx. Coil Outside Dia. Core Size
Inside Dia.
mm inch lbs N feet m inch mm inch mm
Tenax 1616ELC Green 2X1710 9 3/8 425 1890 14,500 4420 24 609 16 406
1716LC 2X1488 10.5 7/16 475 2110 11,550 3520 24 609 16 406
1718LC 2X1498 10.5 7/16 550 2450 9,900 3018 24 609 16 406
1816 010379 12 1/2 500 2220 10,500 3200 24 609 16 406
1818 010361 12 1/2 600 2670 9,000 2740 24 609 16 406
1822 010355 12 1/2 800 3560 6,5000 1980 24 609 16 406

Signode

Strap Name Standard
Color		 Part
Number		 Strap Width Average Strength Approx.
Length per Coil		 Approx. Coil
Outside Dia.		 Core Size
Inside Dia.
mm inch lbs N feet m inch mm inch mm
High–
Strength
Tenex		 2030 Green 2X1365 15.6 5/8 1,100 4890 4,600 1402 24 609 16 406
2038 2X1880 15.6 5/8 1,300 5785 4,000 1220 24 609 16 406
2040 2X1369 15.6 5/8 1,400 6230 4,000 1219 24 609 16 406
2040H 2X1460 15.6 5/8 1,600 7170 4,000 1219 24 609 16 406
2225 2X1355 19.0 3/4 2,500 11120 2,400 732 24 609 16 406
2480 2X1851 25.4 1 2,500 11120 2,200 670 24 609 16 406
10005 2X1842 25.4 1 3,000 13345 1,800 626 24 609 16 406

Seals for Polypropylene & Polyester Strapping

Lightweight Bonded Polyester Cord Strapping

WIDTH COIL LENGTH COILS/BOX Coils/Pallet BREAK STRENGTH
1/4″ 7,800 ft. 2 54 350 lbs.
3/8″ 5,250 ft. 2 54 475 lbs.
1/2″ 3,900 ft. 2 54 680 lbs.
5/8″ 3000 ft. 2 54 792 lbs.
3/4″ 2, 100 ft. 2 54 950 lbs.

Polypropylene & Polyester Seals

Galvanized Wire Buckles

WIDTH USE ON STRAP QTY/BOX
13 mm 3/8″, 1/2″ 2000
16 mm 5/8″ 1000
19 mm 3/4″ 1000

Galvanized Wire Buckles

Heavy Duty Woven Polyester Strapping

WIDTH COIL LENGTH COILS/BOX COILS/PALLET BREAK STRENGTH SYSTEM STRENGTH
5/8″ 2,000 ft. 2 54 1,500 lbs. 2,100 lbs.
5/8″ 2,000 ft. 2 54 2,000 lbs. 2,800 lbs.
3/4″ 1,650 ft. 2 54 2,4000 lbs. 3,360 lbs.
3/4″ 1,650 ft. 2 54 2,700 lbs. 3,780 lbs.
1 1/4″ 600 ft. 4 48 3,285 lbs. 4,590 lbs.
1 1/2″ 600 ft. 4 48 4,700 lbs. 6,580 lbs.
1 1/2″ 600 ft. 4 48 5,400 lbs. 7,560 lbs.

Woven Polyester Strapping

Extra Grip Phosphate Coated Wire Buckles

WIDTH USE ON STRAP GAUGE QTY/BOX
16 mm 5/8″ 0.138 1000
19 mm 3/4″ 0.157 1000
19 mm 3/4″ 0.177 500
32 mm 1 1/4″ & 1 1/2″ 0.275 250

Phosphate Coated Wire Buckles

Composite Polyester Strapping

WIDTH COIL LENGTH COILS/BOX COILS/PALLEt BREAK STRENGTH SYSTEM STRENGTH
5/8″ 2,000 ft. 2 54 1,200 lbs. 2,040 lbs.
3/4″ 1,650 ft. 2 54 1,400 lbs. 2,380 lbs.
3/4″ 1,500 ft. 2 54 2,000 lbs. 3,400 lbs.
1.0″ 1,350 ft. 2 54 2,700 lbs. 4,590 lbs.
1 1/4″ 780 ft. 2 54 3,500 lbs. 5,950 lbs.

Composite Polyester Strapping

Galvanized Wire Buckles

WIDTH USE ON STRAP GAUGE QTY/BOX
16 mm 5/8″ .138 1000
19 mm 3/4″ .157 1000
19 mm 3/4″ .177 5000
25 mm 1.0″ .197 250
32 mm 1 1/4″ .275 250

Galvanized Wire Buckles
